The Q Clamp adjustable cross 130-4 allows a 48.3mm diameter scaffold tube to pass through this fitting at a 30-to-45-degree angle. This clamp holds 3 tubes in total: two vertical tubes at the top and bottom of the clamp, which do not pass through, and the other tube in the diagonal position. It is mainly used for railings on staircases, such as the centre posts, mid-rails, and lower rail supports.

** Please note we do not stock the Q Clamps at our yard; they are ordered directly from our supplier, and lead times will range from 2-5 working days. To get a quote for the Q Clamps, please add the required items to the cart and then check out, and we will get back to you with prices.**

More Info

It is made from galvanised irons and weighs around 1.2kg.
The adjustable cross uses stainless steel grub screws to secure the clamp to the tube.
This Q Clamp is fully adjustable and is approximately 217mm in length.
It has been manufactured to BS EN 1562:1997 standards and has a galvanised hot-dipped finish to BS EN 1461:1999 standards.
This clamp allows angled tubes to meet centrally.
The Q Clamp adjustable cross 130-4 is not recommended to be used on the top of a vertical tube.
Once the tubes have been installed and are fully tightened using a ratchet wrench key, this Q Clamp can withstand an applied slip load of approximately 900kg.

Dimensions and Specifications

Specifications	Dimensions
Condition	NEW
Product Code	130-4
Length	217mm
Fits How Many Tube	3
To Fit Tube Size	48.3mm
Made From	Blackheart Iron
Weight	1.2kg Approx.
Standards	BS EN 1461:1999 & BS EN 1461:1999
