The Clamp on Tee Q Clamp 136-4, or the Add on Tee as it is sometimes called, is used for altering or extending a structure without dismantling the entire build. It connects two 48.3mm diameter scaffolding tubes, one vertically and another horizontally. This clamp’s top section has hinges that allow the clamp to open and close; simply remove the pins and lift the flap-over part to access or install the tube.

** Please note we do not stock the Q Clamps at our yard; they are ordered directly from our supplier, and lead times will range from 2-5 working days. To get a quote for the Q Clamps, please add the required items to the cart and then check out, and we will get back to you with prices.**

More Info

Other features of the Add on Tee 136-4 include:

This item is made from blackheart malleable iron, weighs approximately 0.78kg, is 83mm in width and has an overall length of 100mm. Please note these measurements are only approximate.
The top tube can pass through this clamp in a horizontal position.
The vertical tube cannot pass through and is inserted approximately 25mm to 30mm into the clamp.
Two removal pins will open the top section of this clamp.
This is not a load-bearing fitting, nor should it be used on traditional scaffolding.
Two stainless steel grub screws are included with the Clamp on Tee Q Clamp 136-4.

Dimensions and Specifications

Specifications	Dimensions
Condition	NEW
Product Code	161-4
Length	100mm
Width	83mm
Fits How Many Tube	2
To Fit Tube Size	48.3mm
Made From	Blackheart Iron
Weight	0.78kg Approx.
