The Q Clamp base plate 132-4 is typically used as the base for all vertical posts on tubular structures. This product features two pre-made holes on the plate section where it is secured to the ground, and anchor bolt fixings or through bolts can be used for this; the tube is then inserted in the spigot and fixed in place using two grub screws. This base plate is often used to create handrails and for building any type of structure where vertical tubes must be fixed to the ground, including racking, trolley bays, play areas, stands, and exhibition signage frames.

** Please note we do not stock the Q Clamps at our yard; they are ordered directly from our supplier, and lead times will range from 2-5 working days. To get a quote for the Q Clamps, please add the required items to the cart and then check out, and we will get back to you with prices.**

More Info

The Q Clamp base plate weighs approximately 1.15kg, has a base length of around 152mm, a spigot height of 89mm, a base thickness of roughly 10mm and pre-drilled holes that are 14mm in diameter. This item is made from blackheart malleable iron and has a galvanised finish to BS EN 1461:1999 standards. The Q Clamp base plate is compatible with the 90-degree short tee 101-4 and the 2-way elbow 125-4.

Dimensions and Specifications

Specifications	Dimensions
Condition	NEW
Product Code	132-4
Length	152mm
Spigot	89mm
Thickness	10mm
Fits How Many Tube	1
To Fit Tube Size	48.3mm
Made From	Blackheart Iron
Weight	1.15kg Approx.
Standard	BS EN 1461:1999
